Description

The Metallurgical Microscope YG0663 // YG0664 is a high-performance optical system designed for metallurgical analysis, material science, and industrial inspections. Featuring an Infinity Optical System with bright field, dark field, and polarizing observation modes, this microscope offers versatile imaging capabilities for studying metallic structures, coatings, and surface irregularities. The Seidentopf trinocular head, inclined at 30° with interpupillary adjustment (48-75mm), ensures comfortable long-term use for professionals in metallurgy, electronics, and quality control.

This model is equipped with an extra-wide field eyepiece (EW10x/22mm) and a backward quintuple nosepiece, supporting a variety of Infinity Plan Achromatic Objectives (5x to 100x) to deliver sharp and detailed imaging. The coaxial coarse and fine adjustment system provides precision focusing (<1μm), while the external illumination system (24V 100W halogen light with aspherical collector) ensures consistent brightness and contrast enhancement.

Market Price

The Metallurgical Microscope YG0663 // YG0664 is available in the market within a price range of $4.708 to $5.221 USD, depending on the selected configuration, objectives, and additional accessories. Users can easily request a personalized quotation through Kalstein Plus to find the best option for their needs.

Frequently Asked Questions

• What are the key differences between the YG0663 and YG0664 models?
  Both models share the same advanced optical system, but the YG0664 includes additional objective options and a wider range of magnification for more detailed observations.
• Does this microscope support digital imaging?
  Yes, the YG0663 // YG0664 is compatible with photo adapters for Nikon and Canon SLR cameras, as well as C-mount adapters (0.5x and 1.0x), allowing for digital image capture and analysis.
• Can this microscope be used for failure analysis?
  Absolutely. The Infinity Optical System with bright field and dark field contrast enables detailed inspections of metallic surfaces, cracks, and structural deformations, making it ideal for industrial failure analysis.
• Is the illumination system adjustable?
  Yes, the microscope is equipped with a 24V 100W halogen illumination system with adjustable brightness, as well as Köhler illumination with an aspherical condenser for enhanced clarity.

Advantages and Disadvantages

Advantages:

• Infinity Optical System ensures high-resolution imaging with exceptional precision.
• Bright field, dark field, and polarizing observation modes enhance metallurgical inspections.
• Wide range of Infinity Plan Achromatic Objectives (5x to 100x) for versatile applications.
• Integrated coaxial coarse & fine adjustment system provides high-precision focusing (<1μm).
• Supports digital imaging with Nikon/Canon adapters and C-mount options.
• Ergonomic Seidentopf trinocular head (30° inclined, 360° rotatable) for comfortable long-term use.

Disadvantages:

• High initial investment due to advanced optical and illumination systems.
• Requires periodic maintenance to ensure optimal imaging performance.
• External illumination system requires additional workspace setup.

Field Applications

The Metallurgical Microscope YG0663 // YG0664 is widely used in:

• Metallurgical and material science – Analyzing microstructures, grain boundaries, and metal coatings.
• Industrial quality control – Inspecting welds, fractures, and surface imperfections.
• Electronics and semiconductor industry – Examining circuit boards, microchips, and soldering points.
• Failure analysis and forensic investigations – Identifying structural failures and defects in materials.

Recommendations

To ensure optimal performance and longevity of the Metallurgical Microscope YG0663 // YG0664, consider the following:

• Regularly clean lenses and optical components using proper cleaning solutions.
• Adjust the focusing mechanism and stage positioning for consistent imaging precision.
• Utilize appropriate filters and contrast methods to enhance visualization of metallic structures.
• Store in a dust-free environment and use protective covers when not in use.
