Description
The High Capacity Series for Storage or Transport (Round Canisters) YG1179 // YG1188 is the ultimate cryogenic storage solution for laboratories and biobanks looking to preserve biological samples safely and effectively. These robust yet lightweight aluminum canisters are synonymous with durability and portability, ideal for storing sensitive materials such as sperm, embryos, and other genetic material. With each model offering a maximum capacity of up to 5,022 straws (0.25ml each), the series caters to a wide range of scientific applications. Featuring high thermal efficiency and minimal liquid nitrogen evaporation, the canisters boast a static holding time of up to 86 days, providing peace of mind in both storage and transport. Optional accessories like roller bases and liquid nitrogen dispensing pumps further enhance the versatility and practicality of these canisters.
Market Price
The High Capacity Series for Storage or Transport (Round Canisters) YG1179 // YG1188 is competitively priced between $333 and $505 USD, depending on the model and accessories chosen. This price range reflects the advanced features and significant storage capacities these canisters offer, delivering a cost-effective solution suitable for any laboratory environment.
Frequently Asked Questions
- What is the storage capacity of this series?
It accommodates up to 5,022 straws (0.25ml each), depending on the model. - How long can it maintain cryogenic temperatures?
The canisters offer a static holding time of up to 86 days, thanks to their advanced insulation. - Does it include security features?
Yes, the canisters come with a heavy-duty lockable enclosure for superior security.
Advantages and Disadvantages
Advantages:
- High storage capacity for various biological samples.
- Lightweight and durable aluminum design.
- Exceptional thermal efficiency extends holding times.
- Secure storage with lockable enclosures and numbered canisters.
Disadvantages:
- Higher initial investment compared to basic models.
- Regular maintenance is required to maintain optimal performance.
Field Applications
This storage series is widely used across various fields, including:
- Biobanks: Ideal for long-term preservation of genetic and clinical samples.
- Veterinary Clinics: Used for the cryogenic storage of animal sperm and embryos.
- Research Laboratories: Essential for maintaining biological samples and cell cultures.
- Hospitals and Fertility Clinics: Utilized in the storage of human reproductive materials.
Recommendations
To ensure the longevity and optimal performance of your High Capacity Series for Storage or Transport (Round Canisters) YG1179 // YG1188, conduct regular LN₂ level checks, maintain cleanliness of the interior, and ensure the calibration of temperature monitoring systems. Employing accessories such as roller bases and LN₂ dispense pumps can also improve usability across different settings.
Technical Specifications
| Model | YG1179 | YG1180 | YG1181 | YG1182 | YG1183 | YG1184 | |
|
Maximum
Capacity |
No. of Canister | 3 (0) | 3 (3) | 6 (0) | |||
| No. of Straws (Single Layer) (0.5ml each canister) |
90 | 165 | 792 | ||||
| No. of Straws (Single Layer) (0.25ml each canister) |
204 | 330 | 1788 | ||||
| No. of Straws (Double Layer) (0.5ml each canister) |
— | — | — | — | |||
| No. of Straws (Double Layer) (0.25ml each canister) |
— | — | — | — | |||
|
Performance
|
Volume of LN2 (L) | 2 | 2 | 3 | 6 | ||
| Static Evapouration* (L/Day) | 0.07 | 0.08 | 0.12 | 0.12 | |||
| Static Holding Time** (Day) | 28 | 24 | 26 | 52 | |||
|
Dimensions
|
Opening Diameter (mm) | 30 | 35 | 50 | 50 | ||
| Height (mm) | 399 | 428 | 435 | 482 | |||
| Outside Diameter (mm) | 223 | 204 | 223 | 300 | |||
| Canister Outside Diameter (mm) | 19 | 25 | 38 | 38 | |||
| Outside Height (mm) | 120 | 120 | 120 | 120 | |||
| Empty Weight (kg) | 2.8 | 2.6 | 3.1 | 4.8 | |||
| Full Weight (kg) | 4.5 | 4.4 | 6 | 9.9 | |||
| Shipping Weight (kg) | 5.1 | 4.9 | 5.8 | 8 | |||
| Aditional Features | Includes 3 canisters, lockable cap and protective jacket |
Includes 3 canisters, lockable cap and braces for carrying, no protective jacket |
Includes 6 canisters (height 120mm), lockable cap and protective jacket |
Includes protective jacket only |
Includes 6 canisters (height 120mm), lockable cap and protective jacket |
Includes protective jacket only |
|
| Model | YG1185 | YG1186 | YG1187 | YG1188 | |||
|
Maximum
Capacity |
No. of Canister | 6 (0) | |||||
| No. of Straws (Single Layer) (0.5ml each canister) |
792 | 2244 | |||||
| No. of Straws (Single Layer) (0.25ml each canister) |
1788 | 5022 | |||||
| No. of Straws (Double Layer) (0.5ml each canister) |
— | — | |||||
| No. of Straws (Double Layer) (0.25ml each canister) |
— | — | |||||
|
Performance
|
Volume of LN2 (L) | 10 | |||||
| Static Evapouration* (L/Day) | 0.12 | 0.21 | |||||
| Static Holding Time** (Day) | 86 | 48 | |||||
|
Dimensions
|
Opening Diameter (mm) | 50 | 80 | ||||
| Height (mm) | 552 | 557 | |||||
| Outside Diameter (mm) | 300 | 300 | |||||
| Canister Outside Diameter (mm) | 38 | 63 | |||||
| Outside Height (mm) | 120 | 120 | |||||
| Empty Weight (kg) | 6.1 | 6.2 | |||||
| Full Weight (kg) | 14.5 | S | |||||
| Shipping Weight (kg) | 9 | 9.3 | |||||
| Aditional Features | Includes 6 canisters (height 120mm), lockable cap and protective jacket |
Includes protective jacket only |
Includes 6 canisters (height 120mm), lockable cap and protective jacket |
Includes protective jacket only |
|||
