Product Description
The YG0683-AT Trinocular Biological Microscope is a state-of-the-art instrument designed for advanced research and laboratory applications. Crafted with precision in mind, this microscope offers a range of features that meet the demands of modern scientific exploration. Equipped with an Achromatic Objective system, it provides magnification capacities ranging from 40x to 1000x, allowing for detailed observation of biological samples. The optical system is designed for clarity and precision, utilizing an LED light source for consistent illumination.
The microscope is built with a Seidentopf Trinocular head, which facilitates a comfortable viewing experience with a 30-degree inclination and 360-degree rotation. This makes it ideal for prolonged use without causing strain. Its eyepieces are 23.2mm in diameter with a diopter adjustment feature, enhancing the user’s ability to focus precisely on the specimen. The ergonomic design extends to the focusing mechanism, which includes a coaxial coarse and fine adjustment, ensuring smooth and accurate control with a focusing scale of 0.002mm.
Additionally, the YG0683-AT includes a robust working stage with dimensions of 145x140mm, providing ample space for specimen examination. This mechanical two-layer stage offers a moving range of 76x52mm. Safety features such as a safety stop screw and adjustable tension are also integrated to prevent damage to samples. This instrument includes an Abbe condenser with a numerical aperture of 1.25, associated with an iris diaphragm, rack and pinion adjustment, and a filter holder for diverse viewing requirements.
| Model | YG0683-AT |
| Power Supply Type | DC USB Adapter |
| Transmit Light | 3W LED |
| Light Source Type | LED |
| Condenser N.A. | 1.25 |
| Condenser Type | Abbe |
| Condenser Features | Rack & Pinionↆ↑, Filter Holder, Iris Diaphragm |
| Focusing Knob | Low Position Focusing Knob For Easy Operation |
| Focusing Scale | 0.002mm |
| Focusing Range | 26mm |
| Focusing Type | Coaxial Coarse & Fine |
| Focusing Features | Safety Stop Screw, Tension Adjustable |
| Working Stage Moving | 76x52mm |
| Working Stage Size | 145x140mm |
| Working Stage Type | 2 Layers Mechanical |
| Working Stage Features | Double Slide Holder, Size ≥140x140mm |
| Objective | Achromatic Objective 4x,10x,40x,100x |
| Objective Type | Achromatic |
| Nosepiece Holes | 4 Holes |
| Nosepiece Features | Inward |
| Eyepiece | WF10x/18mm, 2 pcs |
| Eyepiece Diameter | 23.2mm |
| Eyepiece Features | Diopter Adjustable |
| Head Light Path | E80:P20 |
| Head Diopter | Left Adjustable |
| Head Interpupillary | 48~75mm |
| Head Rotation | Head Rotate 360° |
| Head Inclination | 30° |
| Head Type | Seidentopf Trinocular |
| Standard Magnification | 40x-1000x |
| Optical System | Achromatic |
| Upgrade Function | BF+PH+DF+PL+FL |
| Standard Function | BF |
Market Price
The market price for the YG0683-AT Trinocular Biological Microscope can vary depending on the retailer and the region. Generally, high-quality microscopes within this category can range from $1,000 to $2,500 USD. The investment in such equipment reflects not only the precision engineering involved in its manufacture but also its versatility in various research and laboratory environments. Customers are advised to look for authorized dealers or directly from reputable manufacturers like Yulgary to ensure the best purchasing experience and value.
In addition to the stated range, potential buyers should consider additional costs such as shipping or taxes, where applicable. It’s also worth checking for any promotions or discounts that might be available at the time of purchase, which can provide significant savings on this critical laboratory equipment.
Frequently Asked Questions
What is the power source of the microscope?
The YG0683-AT uses a DC USB adapter as its power supply, offering easy connectivity for uninterrupted use.
What are the standard magnification levels available?
This microscope offers a standard magnification range from 40x to 1000x, aided by its Achromatic objective system.
Does the microscope come with any safety features?
Yes, the YG0683-AT includes safety stop screws and tension adjustment features to ensure the protection of your samples during observation.
Advantages and Disadvantages
Advantages:
- Advanced optical system and high-quality LED lighting for clear and precise imaging.
- Ergonomically designed trinocular head for comfortable, extended use.
- Comprehensive focusing system with fine and coarse adjustments for enhanced precision.
Disadvantages:
- Higher initial investment might not be feasible for all budgets.
- Requires careful handling and maintenance for optimal performance over time.
Field Application
The YG0683-AT Trinocular Biological Microscope is ideal for use in academic research, clinical laboratories, and advanced biological studies. Its superior optical system and robust build make it well-suited for examining intricate biological structures and specimens. This microscope can effectively be used in various fields such as histology, cytology, microbiology, and more.
In practical terms, the microscope allows researchers to monitor cellular processes, analyze tissue samples, and conduct detailed investigations into microorganisms with unparalleled clarity. These capabilities make it an invaluable tool for pushing the boundaries of scientific discovery.
Recommendations
For optimal performance, regular maintenance of the YG0683-AT is recommended, including cleaning the lenses with appropriate solutions and storing the equipment in a dust-free environment. Users should also ensure that all components are securely assembled and adjusted before each use to maintain accuracy in imaging.
Enhancing the microscope’s capabilities can be achieved by exploring compatible accessory upgrades offered by Yulgary. Consider attending hands-on training or workshops to fully leverage the microscope’s features and improve your expertise in its applications.
